Specifications

  • Brand Name: BSIDE
  • DIY Supplies: Electrical
  • Origin: CN(Origin)
  • Model Number: ZT-M1/M0
  • AC Current: 8.000A/20.00A
  • AC Voltage: 800.0mV/8.000V/80.00V/800.0V/750V
  • Measuring Resistance Range: 800.0/8.000k/80.00k/800.0k/8.000M ohm
  • Operating Mode: Auto/Manual
  • Measuring Inductance Range: N/A
  • Display Type: Digital Display
  • DC Current: 8.000A/20.00A
  • DC Voltage: 800.0mV/8.000V/80.00V/800.0V/1000V
  • Measuring Capacitance Range: 9.999nF/99.99nF/999.9nF/9.999uF/99.99uF/999.9uF
  • Dimensions: 145*90*44mm
  • Operating Temperature: 0 - 40 ℃
  • True RMS: YES
  • Temperature: (-20~1000)C/(-4~1832)F
  • Frequency Range: 9.999Hz/99.99Hz/999.9Hz/9.999kHz
  • Continuity: YES
  • Non contact Voltage tester: YES
  • Duty Cycle: 1%~99%
  • Diode: YES
  • Square wave output: 50Hz~5000Hz
  • V.F.C: YES
  • Update Rate: 3times/second
  • Data Hold: YES
  • Low Battery Indication: YES
  • Auto Power Off: YES
  • Battery test: YES (1.5V/9V/12V)
  • Battery type: 1.5V AA battery*3(Not include)

BSIDE Digital Multimeter Profesional True RMS 8000 Analogue Tester 20A Current DC AC Voltage Capacitance VFC ohm battery Hz test

Seller:
Alitools rating:
88%
/
Aliexpress rating:
100%
29.37 38.19 $
6   orders
/
3   reviews
Rating: 5

Price history

Price drop notification

Out telegram bot will notify you once the price drops to the desirable one

Customer Reviews

E***s
December 14, 2020

I was disappointed with how poorly they measured low voltage (mV) signals of various frequencies. Signals up to 200 mV are best, though not quite correctly, measured with the cheapest but good value multimeter "Bside 102A"! The other two more expensive Bside ZT-M and ZT-X could not show.

A***n
November 12, 2020

Great product, would recommand it ! The crocodile test clips are useful to test big current as the wire is thicker
