Specifications
- Certification: NONE
- Origin: CN(Origin)
- Coil Number: Autotransformer
- Model Number: KCT-16 current transformer
- is_customized: Yes
- Phase: Single
- Coil Structure: Toroidal
- Usage: Current
- Inner hole size: 16mm / 0.63inch
- Ratio: 100A/33.3mA, 100A/40mA, 200A/66.67mA and so on
- Measuring range: 10%In to 120%In
- Phase angle: less than +-60min
- Dielectric strength: 2.5KV / 1mA / 1min
- Insulation resistance: DC500V / 100Mohm / 1min
- Case: PA66 / UL94-V0
- Bobbin: PA66
- Core: Ferrite or Silicon Steel based on ratio
- Internal struction: Epoxy
- Operation Temperature: -25Celsius to 75Celsius
- Operation Humidity: less than 85%
- Output Connection: 1m twin wire
- Installation: Hang directly on the primary lead
Split Core Current Transformers KCT-16 clamp on CT Easily to install 50A 60A 100A 120A 200A for Ammeter and Power analyzer
