Specifications
- Brand Name: NoEnName_Null
- Model Number: MR63 2RS
- Torque Capacity: 3*6*2.5mm
- Structure: Ball
- Coatings: Chrome Steel/GCr15
- Surface Roughness: Ra 0.05
- Material: Steel
- Bearing Type: Ball
- For Load Direction: Radial
- Construction: Single Row
- Seal Type: Sealed
- Part Number: MR63 2RS
- For Shaft Diameter: 3mm
- Bore Dia (d): 3mm
- Bore Dia Tolerance: -0.008mm to 0
- For Housing ID: 6mm
- Outer Dia (D): 6mm
- Outer Dia Tolerance: -0.008mm to 0
- Width (B): 2.5mm
- Width Tolerance: -0.12mm to 0
- Ring Material: 52100 Chrome steel
- Ball Material: 52100 Chrome steel
- Cage Material: 300 Series Stainless Steel
- Shield Material: 300 Series Stainless Steel
- Dynamic Load Rating (Cr) (Newtons): 178
- Static Load Rating (Cor) (Newtons): 59
- Max Speed (Grease) (X1000 RPM): 24
- Max Speed (Oil) (X1000 RPM): 27
- Lubrication: G
- Shaft Mount Type: Press Fit
- Temperature Range: -20 to 120
- ABEC Rating: ABEC-3
- Radial Clearance Trade No.: C0
- Radial Clearance: 0.002mm to 0.013mm
- Ball Qty: 8
- Ball Dia: 0.8000mm
- Weight (grams): 0.25
MR63-2RS Bearing ABEC-3 10PCS 3x6x2.5 mm Miniature MR63RS Ball Bearings Blue Sealed L-630DD
9.41
$
3
orders
/
1
reviews
