10.1 inch  2K  lcd display screen  2560*1600 60Hz panel with HDMI USB driver board 45 pins ► Photo 1/6
10.1 inch  2K  lcd display screen  2560*1600 60Hz panel with HDMI USB driver board 45 pins ► Photo 1/6
10.1 inch  2K  lcd display screen  2560*1600 60Hz panel with HDMI USB driver board 45 pins ► Photo 2/6
10.1 inch  2K  lcd display screen  2560*1600 60Hz panel with HDMI USB driver board 45 pins ► Photo 3/6

Specifications

  • Brand Name: Wisecoco
  • Product Type: TFT
  • Display Size: 10.1 Inch
  • Model Number: LTL101DL03-T01
  • Screen Type: Capacitive Screen
  • Compatible Brand: Universal
  • Model Name: LTL101DL03-T01
  • Screen Size: 10.1inch
  • Screen Type: LCM, a-Si TFT-LCD
  • Pixel Number: 2560*1600 2K
  • Arrangement: RG/BW LCD PenTile
  • Active Area(mm): 216.576 * 135.36 (H*V)
  • Outline(mm): 232.22* 156.92*5.2 (H*V*D)
  • Treatment: Glare (Haze 0%), Hard coating (2H)
  • Luminance: 370 nits
  • Contrast Ratio: 800 : 1 (Typ.) (TM)
  • Backlight: 7S6P WLED , 12K hours , With LED Driver
  • Refresh Rate: 60Hz
  • Signal Type: eDP (4 Lanes) , Connector , 45 pins
  • Voltage Supply: 3.3V (Typ.)
  • Used for: laptop Pad&Tablet

10.1 inch 2K lcd display screen 2560*1600 60Hz panel with HDMI USB driver board 45 pins
